Model Q-2 & Q-4 Rack Power Supply

The Model Q-2 and Model Q-4 power supplies transform 120 / 240 VAC, 50 / 60 Hz input power into unregulated 24 VDC. Each output is rated for 300 mA of load current and can be paralleled (via the rack wiring) for increasedcurrent capacity.The Model Q-2 has two outputs, the Model Q-4 has four outputs.The Model Q-2 and Model Q-4 are available in four input voltage configurations: 120 VAC / 50 Hz, 120 VAC / 60 Hz, 240 VAC / 50 Hz, and 240 VAC / 60 Hz.

Features/Benefits
  • Provides two or four unregulated 24 VDC outputs rated 300 mA
  • Four input voltage configurations
  • Outputs can be paralleled for increased current capacity
  • Power switch controls input line voltage
  • Fits all standard size card racks

For more information… click here

Model LS-200



The Model LS-200 Load Switch exceeds industry standards by featuring two LED indicators per individual circuit (one for the input, one for the output). This feature provides a means of quickly and accurately conveying information regarding the input and output states of each circuit to assist technicians trouble shooting potential cabinet problems.  It is designed to meet or exceed NEMA Standards TS 1-1994 and TS 2-1998 and is compatible with Type 170 installations.  Model LS-200 Load Switches are three circuit, solid state devices that are constructed with extruded aluminum exterior components which promote rapid heat dissipation to ensure lower operating temperatures and dependable, long term operation.

For more information… click here

Model FL-200





Meets or exceeds NEMA Standards TS1-1994 & TS 2-1998. Compatible with Type 170 installations. Model FL-200 Flashers are dual circuit, solid state devices that are  constructed with extruded aluminum exterior components which promote rapid heat dissipation to ensure lower operating temperatures and dependable long term operation.

For more information… click here
